ULTRA E91T-1 Flux Cored Welding Wire

ULTRA E91T-1 Low Alloy Flux Cored Welding Wire for High Temperature & Creep-Resistant Applications

ULTRA E91T-1 flux cored welding wire is a low-alloy, gas-shielded FCAW wire developed for high tensile and high-temperature service applications. Classified as AWS A5.29 E91T1-B3C/M, this wire is specially formulated to provide excellent creep resistance, crack resistance, and long-term strength at elevated temperatures.

Manufactured to meet stringent quality standards, ULTRA E91T-1 FCAW wire is widely used in power generation, oil & gas, refinery, and pressure equipment fabrication, where weld reliability and thermal stability are critical

ULTRA E91T-1 Welding Wire Classification & Standards

The ULTRA E91T-1 flux cored welding wire conforms to internationally recognized standards and approvals:

AWS A5.29 classification E91T1-B3C/M

Low alloy flux cored welding wire for high tensile steel applications

Suitable for high temperature and creep-resistant service

Designed for CO₂ or Argon + CO₂ mixed shielding gas

These classifications confirm the wire’s suitability for critical pressure and high-temperature welding applications.

BIS approved

Typical Chemical Composition of ULTRA E91T-1 Weld Metal

The undiluted weld metal chemistry of ULTRA E91T-1 FCAW wire is carefully controlled to achieve high temperature strength and creep resistance. Typical composition includes approximately 0.08% Carbon, 1.20% Manganese, 0.50% Silicon, 2.25% Chromium, and 1.00% Molybdenum.

This Cr-Mo alloy system provides enhanced oxidation resistance, improved creep strength, and superior performance under prolonged thermal exposure.

Mechanical Properties of ULTRA E91T-1 Flux Cored Welding Wire

The weld metal deposited by ULTRA E91T-1 welding wire exhibits excellent mechanical performance. Typical ultimate tensile strength is around 620 MPa, with yield strength approximately 520 MPa. The weld metal also delivers good elongation of about 26% and impact toughness around 60 Joules at -29°C.

These properties ensure structural integrity, resistance to thermal fatigue, and reliable performance in high-pressure and high-temperature environments.

Key Features of ULTRA E91T-1 Flux Cored Welding Wire

Excellent mechanical strength at elevated temperatures

Low hydrogen weld metal deposit

Good impact strength at sub-zero temperatures

High crack resistance and creep resistance

Smooth, stable arc with low spatter

Designed for critical pressure and alloy steel welding

These features make ULTRA E91T-1 FCAW wire a dependable choice for long-service, high-temperature applications.

Recommended Welding Parameters for ULTRA E91T-1 FCAW Wire

ULTRA E91T-1 flux cored welding wire is available in 1.2 mm and 1.6 mm diameters. The recommended amperage range is approximately 140 to 300 amperes, depending on wire diameter and welding position. Welding should be carried out using DCEP (Electrode Positive).

The wire is suitable for use with CO₂ shielding gas or Argon-CO₂ mixed gas. When using mixed shielding gas, it is recommended to reduce the voltage by 1 to 2 volts to maintain arc stability and bead profile.

Packing Details of ULTRA E91T-1 Flux Cored Welding Wire

The wire is supplied in 15 kg vacuum-sealed packs, layer wound on durable plastic spools. Vacuum packaging prevents moisture absorption, helping maintain low hydrogen levels, stable feeding, and consistent welding performance.

Typical Applications of ULTRA E91T-1 Welding Wire

The ULTRA E91T-1 flux cored welding wire is commonly used in:

Boiler tubes and headers

Power plant piping systems

Pressure vessels and heat exchangers

Oil and gas transmission pipelines

Oil refineries and petrochemical plants

Construction equipment, farm machinery, and rolling stock

It is especially suited for applications requiring creep resistance, thermal stability, and high weld integrity.

Why Choose ULTRA E91T-1 Flux Cored Welding Wire from Us?

As an experienced flux cored welding wire manufacturer, we ensure:

• Precise alloy control for critical applications



• Compliance with AWS and BIS standards



• Proven performance in power, refinery, and oil & gas sectors



• Technical support from qualified welding professionals



Our ULTRA E91T-1 FCAW wire is trusted by fabricators and EPC contractors for high-temperature strength, reliability, and metallurgical consistency.

Preheat & Post-Weld Heat Treatment Guidelines

For optimal performance, ULTRA E91T-1 welding wire should be used with proper preheating and post-weld heat treatment (PWHT) in accordance with the approved Welding Procedure Specification (WPS). This ensures maximum toughness, crack resistance, and long-term service reliability.

ULTRA 91T-1

AWS A5.29: E91T1-B3C/M

High Strength, Low Alloy Flux Cored Wire

• Power plant piping

• Boiler tubes

• Pressure vessels

• Refineries

• Oil & gas transmission pipelines

Typical Applications

Icon by Freepik

Download Product PDF

Key Features

• Excellent mechanical strength at elevated temperatures

• Low hydrogen weld deposit

• Good impact strength

• Crack resistance and creep resistance

• Smooth arc and low spatter

FLUX CORED WIRE

Bulk Supply & Technical Support for ULTRA E91T-1 Welding Wire

For bulk orders, project-specific supply, or technical assistance related to ULTRA E91T-1 flux cored welding wire, our technical team is available to support your welding requirements.
